Rated current: 1A version: 1A (1.16A in overrange)

10A version: 10A (11.6A in overrange)

100A version: 100A (116A in overrange)

Voltage drop: 60mV for rated current

Resolution: 1A version: 10μA (1μA in moving mean mode)

10A version: 100μA (10μA in moving mean mode)

100A version: 1mA (100μA in moving mean mode)

Accuracy: 0.5% +/- 3 digits (normal mode resolution, 23ºC±1K)

Power supply rechargeable Li-Ion battery (internal)

Battery life: >24h

Connector electrical: USB (f) connector – only for charging

M8 screws for current measurement

Connector optical: Standard F-SMA for multimode fiber (50/125μm or 62.5/125μm)

Max. cable length: >200m

Sampling rate: 6 samples per second

Ambient temperature: storage/operation: -10 – 50ºC (14 - 122ºF)

Size: 98 x 100 x 28 mm
